CHM-T36 Dual Heads Desktop SMT Pick And Place Machine Easy Operation
Description
CHM-T36 is a small desk-top pick and place machine of Hunan Charmhigh Electromechanical Equipment Co., Ltd.
It has 29 tape feeding stacks, support for stick feeders, 8 general IC stacks preset at the front end and several self-defined IC tray stacks in the rear integrated operation with built-in industrial computer.
Besides, CHM-T36 possesses the capability of automatic detection of Z axis.
1) Laser positioner, easy for online programming.
2) Own vacuum testing, if one component suck crooked, will throw to the deposit area, then re-pick and place again..
3) Dual pick and place head design helps increase output, 2pcs juki nozzles, change quikcly and easy.
4) Dual built-in mute type pumps (cost and room saving, no need to prepare additional pump)
5) Standard 8G SD card, mass storage of CSV working file
6) Ful touch screen interface input/output, easy operation
7) Integrated Automatic Feeders Automatic Nylon Spool Wheel
8) support single step, easy operation.
| CHM-T36 Specifications |
| Dimensions | 930mm(L)×690mm(W)×310mm(H) |
| Weight | 37kg |
| Power Supply | AC220V (50Hz, single phase) / AC110V (60Hz, single phase); 250W |
| Air Supply | No external air supply required |
| Vacuum Generation | Built-in vacuum pump |
| Mounting Head Quantity | 2 |
| Mounting Speed | 6000cph (optimal) |
| Control Accuracy | 0.025mm |
| Component Type | 0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
| PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 10mm(L)×10mm(W)～345mm(L)×410mm(W) |
| PCB Conveying | Manual operation |
| Nozzle Change | Manual operation |
| Control System | Embedded real-time operating system, 5-inch touch screen |
| Drive System | X&Y-axis driven by stepping motors; Z-axis capable of reset detection; all motors adopting flexible S-curve acceleration and deceleration; tape puller automatic reset supported |
| Transmission System | Synchronous belt + polished rod |
| Feeding System | 29 tape feeding stacks (8mm:22,12mm:4,16mm:2,24mm:1；customization supported), 8 preset general IC stacks, worksurface custom IC trays supported |
| Positioning Mode | Laser positioning |
